Horizontal Machining Center

Manufacturer MORI SEIKI Model NH4000DCG Year 2010
Specification Control: MSX-701Ⅳ(F-31iA) (MAPPS 4)
Table: 400×2APC,  B-Axis: 0.001°
Capacity: 400kg
Spindle: 14,000rpm, BT40, ATC60
Travel:XYZ: 560×560×630
Distance from pallet surface to spindle centerline:80-640
・Through-spindle coolant(7.0MPa)
・manual measurement (tool and work piece setter)
・Touch sensor(Spindle)/ Renishaw OPM60
・Touch sensor(Table)/Metrol
・Chip-conveyor& bucket
・Relocation detection device
詳細はこちら

Horizontal Machining Center

Manufacturer OKUMA Model MILLAC-525H Year 2007
Specification Control: Fanuc-16iMB
Table: 400×2APC, Indexing :0.001°(Arbitray)
Capacity: 350kg
Spindle: 8,000rpm, BT50, ATC30
Travel:XYZ: 520×450×520
Spindle center to Pallet:50-500
・Through-spindle coolant (3.5MPa)
・Automatic tool measurement (Including breakage detection)
・Automatic measurement (Renishaw MP10)
・Chip-conveyor& bucket
詳細はこちら

Horizontal Machining Center
SOLD OUT

Manufacturer OKUMA Model MA-60HB【SOLD OUT】 Year 2003
Specification Control: OSP-E100M (Interactive function-MAP)
Table: 630×2APC, Indexing:1deg.
Loading capacity: 1200kg
Spindle speed: 5,000rpm, BT50, ATC40
Travel:XYZ: 1000×800×810
・Oil hole device
・Helical cutting ・Synchronized tapping Ⅱ
・Tool length/dia. compensation
・Chip-conveyor
詳細はこちら

Horizontal Machining Center
SOLD OUT

Manufacturer MAKINO Model a81【SOLD OUT】 Year 2006
Specification Control: Professional 5
Table: 630×2APC, B-Axis:0.0001°(NC Rotary)
Loading capacity: 1,500kg
Travels :XYZ: 900×800×1020
Spindle: 20,000rpm(Ball screw core cooling), HSK-A100, ATC60
・ Through-spindle coolant (3.0Mpa)& Air blow
・ Scare feedback(XYZ-Axis)
・ Automatic work measuring system(Maker-MARPOSS製)
・ Non-contact tool measuring apparatus (Using Blum-Novotest製Laser control NT)
・ Super GI.4
・ Chip-conveyor
詳細はこちら

Horizontal Machining Center
SOLD OUT

Manufacturer MORI SEIKI Model NH4000【SOLD OUT】 Year 2006
Specification Control: MSX-501Ⅲ(Fanuc-18iMB)
Table: 400×2APC,  B-Axis: 1°
Spindle: 14,000rpm, BT40, ATC40
Travel:XYZ: 560×560×630
Capacity: 400kg
Swing DiameterxMax.machining high: φ630x900
・Chip-conveyor
詳細はこちら

Horizontal Machining Center
SOLD OUT

Manufacturer OKUMA Model MA-400HA【SOLD OUT】 Year 2017
Specification Control: OSP-P300MA (Conversation MAP)
Table: 400×2APC, Indexing:0.001°(
Loading capacity: 400kg
Travel:XYZ: 560×610×625
Spindle : 8,000rpm, BT40(BBT), ATC60
・ Through-spindle coolant
・ Through-spindle airblow
・ absolute linear scale (XYZ-Axis)
・ Coolant device for Ballscrew &Hydraulic fluid
・ Automatic tool length compensation(Renishaw-TS34)
・ Automatic measurement with Origin correction(Renishaw-OMP60)
・ Helical Interpolation ・Sychronized tapping Ⅱ ・Optional angle chamfering/ Corner rounding
・ Super-NURBS ・Mist collector ・Automatic extinguish device
・Chip-conveyor
詳細はこちら

Horizontal Machining Center
SOLD OUT

Manufacturer OKUMA&HOWA Model MILLAC-525H【SOLD OUT】 Year 2004
Specification Control: OH-OSP-HMi (Interactive)
Table: 400×2APC, Indexing:0.001°
Loading capacity: 350kg
Spindle speed: 8,000rpm, BT50, ATC30
Travel:XYZ: 520×450×520
Distance from spindle center to pallet surface:50-500
・Automatic tool length measuring and breakage detection function
・Interactive manual type centering function
・Hi cut
・Lift up chip-conveyor
詳細はこちら

Horizontal Machining Center
SOLD OUT

Manufacturer OKUMA Model MA-600HB【SOLD OUT】 Year 2005
Specification Control: OSP-E100M (Conversation MAP)
Table: 630×2APC, Indexing: 0.001°
Loading capacity: 1200kg
Travel:XYZ: 1000×900×1000
Spindle: 12,000rpm、 BT50、 ATC150
・Through-spindle coolant
・Through-Spindle air blow
・Spindle head cooling device
・Auto.tool length compensation (including breakage detection)
・Auto.measurement(Including origin correction)(Renishaw MP10)
・Helical Interpolation ・Synchronized tappingⅡ ・DNC-DT
・Chip conveyor
詳細はこちら

Horizontal Machining Center
SOLD OUT

Manufacturer OKUMA&HOWA Model MILLAC-630H【SOLD OUT】 Year 2006
Specification Control: Fanuc-16iM
Table: 630×2APC, Indexing:0.001°
Loading capacity: 1200kg
Spindle speed: 10,000rpm, BT50, ATC80
Trevels:XYZ: 1020×820×820
Distance from table center to spindle nose:150-970
・Through spindle
・Scare feed back(XYZ-Axis)
・Ball screw and hydraulic oil cooling device
・Automatic tool length measuring(including breakage detection(Touch sensor)
・Automatic centering function (Renishaw)
・Helical interpolation・Rigid tap ・Optional charmfering
・Lift-up Chip conveyor
詳細はこちら

Horizontal Machining Center
SOLD OUT

Manufacturer OKUMA Model MA-50HB【SOLD OUT】 Year 1999
Specification Control: OSP-U100M
Table: 500×2APC, B-Axis: 0.001°
Loading capacity: 800kg
Spindle: 5,000rpm, BT50, ATC60
Travels:XYZ: 700×800×700
Distance from Table to spindle center:50-850
・DNC-B
・Spindle cooling device
・Helical interpolation ・Rigid Tapping
・Lift-up chip-conveyor
詳細はこちら

Horizontal Machining Center
SOLD OUT

Manufacturer OKUMA Model MA-600HB【SOLD OUT】 Year 2011
Specification Okuma MA-600HB, Year2011
Control: OSP-P200M(Conversation)
Table: 630×2APC, Indexing: 1°
Loading capacity: 1200kg
Travel:XYZ: 1000×900×1000
Spindle: 6,000rpm、 BT50、 ATC60
・Through-spindle coolant
・Hi cut Pro ・DNC-T1
・Auto.tool length compensation (including breakage detection)
・Auto.measurement(Including origin correction)(Renishaw-OMP60)
・Helical Interpolation ・Synchronized tappingⅡ
・Optional angle chamfering
・Chip conveyor
詳細はこちら

Horizontal Machining Center
SOLD OUT

Manufacturer Okuma Howa Model MILLAC-550H【SOLD OUT】 Year 2001
Specification Control:OH-Fanuc-16iM
Table:550×550×2APC, Loading Capacity:800KG
Travel:XYZ:800×800×700, B axis:0.001°deg.
Spindle:10,000rpm、 BT50、 ATC40
● Helical Interpolation、・Optional angle chamfering/ Corner rounding
● Automatic tool length measurement, Tool breakage detection device(Touch)
● Automatic centering device
詳細はこちら

Horizontal Machining Center
SOLD OUT

Manufacturer OKUMA Model MA-500HB【SOLD OUT】 Year 2004
Specification Control:OSP-P200M
Table:500×500×2APC, Loading capacity:800KG
Travel:XYZ:700×900×780, B Axis: 1° Indexing
Spindle:6,000rpm、 BT50、 ATC60
・ spindle through coolant / ・Spindle through air blow
・ Automatic Tools length compensation(Renishaw-MP4)
・ Automatic measurement(Including origin compensation)(Renishaw-OMP60)
・ Helical Interpolation ・Synchronous tapping Ⅱ
・Chipconveyor
詳細はこちら

Horizontal Machining Center
SOLD OUT

Manufacturer MAZAK Model HCN6800-Ⅱ【SOLD OUT】 Year 2011
Specification Control: MAZATROL MATRIX NEXUS
Table: 630×2APC, Intexing: 0.0001°(NC Rotary)
Loading capacity: 1500kg
Travel:XYZ: 1050×900×980
Spindle: 10,000rpm、 BT50、 ATC80
・ Scale feedback(X,Y,Z-axis)
・ Spindle through coolant(15kgf)
・ Automatic Tool length measuring&Tool breakage detection device
・ Touch sensor (Renishaw OMP60)
・ ball screw core cooling as standard(X,Y,Z-axis)
・ Mist collector
・ Lift Chip-conveyor
